Dobot MG400
Dobot Robotics · Starting from $2,581 · Get a current price · Simulate it first
Overview
Ultra-compact desktop 4-axis SCARA-style cobot with a footprint smaller than an A4 sheet of paper. Designed for light pick-and-place, dispensing, PCB handling, and education. Offers drag-to-teach and vibration suppression at a fraction of the cost of full-size cobots.
Will the Dobot MG400 do your task? Simulate it before you buy.
Four cobots on the same palletizing task, simulated before purchase.
We build your station in a simulator with the Dobot MG400 and one or two alternatives, and send you video plus cycle time, parts per shift, reach and payload check, and a payback estimate. Scoping is free, and every project is quoted individually.
Software & 3D models
- URDF: yes
- MuJoCo: not found
- Isaac Sim (USD): not found
- Gazebo: not found
- CAD (STEP): not found
- SDK: yes
- ROS: yes
- ROS 2: yes
- RoboDK: yes
Checked 2026-10-17. Links are not published; we share them with clients.
Variants & pricing
| Variant | Status | Available | Current price |
|---|---|---|---|
| MG400 | available | 2020 | $2,581 |
Get a price for the Dobot MG400
We work from Hangzhou with Chinese and international robot makers. Tell us what you need and we check the current price, lead time and delivery to your country, and reply by email. Our fee comes from you, never from the seller.
A real person reads this. Reply within 2 business days. How we help buyers of robots from China →
Full price history
| Price | Date | Variant | Source | Note |
|---|---|---|---|---|
| $2,581 | 2026-10-16 | MG400 | OpenELAB (EU distributor) | Listed EUR 2,728.90 incl. 19% German VAT with Add to cart, marked in stock; EUR 2,293.19 excl. VAT, converted from the excl.-VAT price at the ECB reference rate 1.1253 USD/EUR of 2026-10-16. Distributor price, not a Dobot list price. Arm with integrated controller, no end-effector. |
| $2,890 | 2024-01-01 | MG400 | Dobot official / Pololu listing | Arm only, no end-effector |
Sensors
- Joint position encoders
- End-effector I/O port
Locomotion
fixed mount
Manipulation
Arms: 4 DOF · Hands: Tool flange; optional suction cup, gripper, or pen end-effector
Use cases
pick-and-place, dispensing, PCB handling, light assembly, sorting, education, small-batch labs
Software
OS: DobotStudio / SCStudio · SDK: ✓ · ROS: ✗ · Open source: ✗ · Languages: Lua, Python, C++
Key facts
- Reach: 440 mm. Repeatability: ±0.05 mm.
- Payload: 500 g rated, 750 g maximum.
- Footprint 190 × 190 mm — smaller than an A4 sheet of paper.
- Vibration suppression algorithm reduces residual vibration by 70%.
- Drag-to-teach programming via DobotStudio.
- Optional sliding track module extends working envelope.
- Power: 150 W, 100–240 V AC input, 48 V rated. Controller and servo drive are built into the base.
- Max joint speed 300°/s on all four axes; Dobot publishes no TCP (linear) speed for the MG400.
- IP20, operating environment 0–40 °C (official spec table and FAQ).
About Dobot Robotics
Developer of affordable desktop and collaborative robot arms for education, research, and light industrial use.
https://www.dobot-robots.com · Founded: 2015 · HQ: Shenzhen, China
